wholesale Filled Copper PTFE Tube price
Specification
| OD(mm) | Wall Thickness(mm) | Length(mm) | |
| Paste Extruded Tube | 0.5~25 | 0.1~2.5 | According to customer’s request |
| Plug Extruded Tube | 25~250 | 1.5~8 | According to customer’s request |
| Molded Tube | 25~2000 | 5~500 | 100~300 |
There are many specifications are in stock.The data is too much, it’s not convenient to list here.
And special specifications can be customized.
If you have any interest, please contact us. We will response to you as soon as possible.
Properties
| ITEM | Properties | Unit |
| Apparent density | 2.10-2.30 | g/ cm3 |
| Tensile Strength | 25 | Mpa |
| Elongation at break | ≥150 | % |
(1) PTFE TUBE Anti-corrosion in all kinds of chemicals including nitric acid & aqua fortis.
(2) PTFE TUBE Characteristics: Low friction, Virtually no lubrication requirement, Light weight, Resistant to corrosion and abrasion, Impact resistance, Stable chemical properties, Oil resistance, High temperature resistance, Low temperature resistance, water resistance and so on.
(3) PTFE TUBE working temperature:-55~+260°C.
(4) PTFE TUBE Electric insulation; good dielectric in mediums.
(5) PTFE TUBE filled ptfe tube products(plastic tube pipe) Made of high-speed mixing polytetrafluoroethylene resin and certain filling resin
(6) PTFE TUBE Soft and formable, outstanding Chemical properties etc.
Filled with other products enhance certain aspects of performance.
|
Glass Fiber: |
Increases compressive strength, rigidity and wear. |
|
Carbon: |
Increases compressive strength, hardness, wear, and load properties. |
|
Graphite: |
Reduces coefficient of friction |
|
Molybdenum Disulfide: |
Increases hardness, stiffness, and wear |
|
Bronze: |
Increases hardness and wear resistance |
